Brand:A-B
Model:140EX
Submodel:HE1C3-C50MCCB
Frame:H-FRAME
Current Rating:50A
Poles:3P
Breaking Capacity:TM 18KA
Application:Industrial Control Systems
Certifications:CE, UL, IEC Standards Compliant
Protection Rating:IP20
Mounting Type:Panel Mount
The Rockwell Automation 140EX-HE1C3-C50MCCB H-FRAME Circuit Breaker is an advanced solution for industrial power distribution systems. It offers reliable and efficient protection against overcurrent and short circuits, ensuring safe operation of electrical equipment.
Key Features:
– Rated for 50A at 3 poles
– Capable of interrupting fault currents up to 18kA
– Designed for harsh industrial environments
– High-quality materials ensure long-lasting durability
– Easy installation and maintenance
– Compliant with international safety standards
Application Areas:
– Industrial machinery
– Power distribution systems
– Manufacturing facilities
– Energy production and distribution
Installation Instructions:
1. Turn off the main power supply before installation.
2. Identify the correct position for the circuit breaker based on your wiring diagram.
3. Securely mount the circuit breaker onto the DIN rail or panel.
4. Connect the incoming and outgoing wires according to the wiring diagram.
5. Restore the main power supply and test the circuit breaker for proper operation.
Maintenance Tips:
– Regularly inspect the circuit breaker for any signs of wear or damage.
– Keep the installation area clean and free from debris.
– Follow the manufacturer’s recommendations for periodic testing and inspection.
