Operating Voltage (V):650V
Current Rating (A):122A
Switching Frequency (kHz):20 kHz
Thermal Resistance (°C/W):1.5°C/W
Insulation Resistance (MΩ):≥ 10^9
Operating Temperature Range (-°C to +°C):-40°C to +125°C
Package Size (mm):31.6 x 34.8 x 12.8
Cooling Method:Active Air Cooling
Control Interface:Digital Signal Input
Max Power Handling (W):7700W
The ABB 5SNA 0600G650122 IGBT module is a state-of-the-art solution for demanding power electronics applications. It is engineered with advanced semiconductor technology to provide exceptional efficiency and reliability under rigorous industrial conditions.
Featuring a robust design, this IGBT module offers unparalleled switching performance, enabling precise control over power flows in industrial automation systems and electrical drives. Its high power rating and wide operating temperature range make it suitable for a variety of environments and applications.
Designed with ease of integration in mind, the module utilizes faston terminals for quick and secure connections, ensuring minimal downtime during installation and maintenance processes. The inclusion of thermal conductivity cooling ensures optimal heat dissipation, prolonging the lifespan of the module.
Withstanding extreme temperatures and offering high insulation resistance, the ABB 5SNA 0600G650122 module is an ideal choice for applications requiring high reliability and performance. Its protection class IP20 safeguards against accidental contact and dust ingress, further enhancing its suitability for industrial environments.
Innovative features such as efficient current handling and precise switching capabilities make this IGBT module a preferred solution for optimizing energy consumption and system performance in various industries. Backed by ABB’s commitment to quality and customer service, users can expect exceptional support throughout the lifecycle of their project.
