Allen Bradley AB 1746-NR8 SLC 500 Analog Input Module

Number of Channels:8

Common Mode Voltage Range:-10V to +10V

Absolute Input Voltage:+/- 10V DC or 10V AC RMS (Max)

Input Range:-10V to +10V

Overvoltage Protection:10V AC RMS

Backplane Current Draw:≤ 50MA @ 5V

Isolation:Backplane: 500VDC

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0°C to 60°C

Environmental Conditions:5% to 95% relative humidity (non-condensing)

    The Allen Bradley AB 1746-NR8 SLC 500 Analog Input Module is designed for seamless integration into complex industrial automation systems, ensuring accurate and reliable data acquisition.

    This module supports a wide range of input voltages and currents, making it suitable for diverse industrial applications from temperature control to process monitoring.

    With its high-resolution input capability, the module provides exceptional precision, enabling operators to make informed decisions based on real-time data.

    The open type enclosure ensures durability and protection against dust and light impacts, ideal for harsh industrial environments.

    The easy-to-install chassis mounting facilitates quick setup, saving valuable time and resources during system deployment.

    Backplane current draw of 35 MA at 5 V and 85 MA at 24 V ensures efficient power consumption, contributing to lower operational costs.
