Measurement Range:DC to 40 GHz
Frequency Resolution:1 Hz to 1 MHz
Dynamic Range:120 dB
Sampling Rate:2 MSa/s
Input Power Range:-10 dBm to +10 dBm
Calibration Options:Automated and manual calibration
Operating Temperature:0°C to 45°C
Dimensions (WxDxH):345 x 444 x 300 mm
Weight:21.5 kg
The ANRITSU KL2300A is engineered with cutting-edge technology, providing unparalleled performance for demanding electronic testing tasks. Its high sampling rate and wide bandwidth ensure accurate capture of even the fastest signals, making it indispensable in R&D environments.
Equipped with a 12-bit resolution, this oscilloscope offers exceptional detail in signal analysis, allowing engineers to discern subtle nuances in complex waveforms. Its extensive real-time memory depth ensures no missed details in fast-changing signals.
With versatile trigger modes, including edge, video, and pattern triggering, the ANRITSU KL2300A simplifies setup and analysis for a wide range of testing scenarios. Whether you’re dealing with sequential events or intricate signal patterns, this oscilloscope delivers precise and reliable results.
The input impedance of 1 MΩ ensures minimal signal distortion during measurement, preserving the integrity of the original signal. This feature is crucial for maintaining accuracy when testing sensitive electronic components.
The KL2300A is designed for maximum flexibility with its power supply options. It supports AC, DC, and battery power, ensuring uninterrupted operation in various field conditions. This makes it an ideal tool for on-site testing and troubleshooting, complementing its capabilities in laboratory settings.
