GE DS3820PSCB1C1B – Advanced Power Supply for GE’s Mark IV Turbine Systems

Output Voltage (+5V):5 Volts

Output Voltage (-15V):±15 Volts

Module Housing Material:Metal

Input Voltage Range:AC Input Module

Power Rating:High Capacity

Monitoring Capabilities:Flame Loss, Fire, Vibration

Maintenance Support:GE-Provided Technical Assistance

    This power supply module from General Electric is an essential component in the Mark IV series of gas and steam turbine control systems. Designed with advanced technology, it provides stable power supply with precise voltage control for efficient system operation.

    Equipped with a metal housing, the DS3820PSCB DS3820PSCB1C1B ensures durability and protection against environmental factors. It utilizes multiple DS3800 PCBs, along with additional components, to deliver reliable performance under varying operational conditions.

    The module features a robust design that includes a collar clamp, smaller polyester vinyl capacitors, capacitors of other materials, potentiometers, LEDs, thermistors, amplifiers, transistors, and spare PTH, providing a comprehensive solution for power management.

    Integrated with sophisticated circuitry, the DS3820PSCB DS3820PSCB1C1B is capable of monitoring and protecting turbine systems from potential issues such as loss of flame, fire, and vibration, ensuring safety and reliability.

    Backed by GE’s technical support, this power supply offers peace of mind for users, providing assistance with installation, maintenance, and troubleshooting. It is meticulously crafted to meet the stringent demands of industrial turbine operations, delivering exceptional performance and longevity.
