GE SR469 – 469-P5-H1-A20-E Motor Management Relay

Relay Type:Motor Management Relay

Model:SR469-P5-H1-A20-E

Manufacturer:GE-FANUC

Control Power Supply Voltage:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

Phase Current Capacity:5 A

CT Secondary Rating:5A

Display:Enhanced display, larger LCD

Humidity Resistance:Up to 90%, non-condensing

RS-232 Interface Baud Rate:Programmable up to 19,200 baud

Analog Output:Four (4) 4 to 20 mA analog outputs

Temperature Measurement Inputs:3 wire: 100 Ω Platinum, 100 Ω Nickel, 120 Ω Nickel, 10 Ω Copper

    The GE SR469 469-P5-H1-A20-E Motor Management Relay boasts a compact yet robust design, specifically engineered to withstand harsh industrial environments. Its advanced microprocessor ensures precise control over motor operations, enhancing efficiency and prolonging the lifespan of the machinery.

    Equipped with multiple RTD inputs, this relay accurately measures the actual temperature and hottest point of the motor system, providing critical data for predictive maintenance and operational optimization. The RTDs utilize high-precision materials like Nickel and Platinum, ensuring reliability and accuracy.

    Featuring an enhanced front panel with a draw-out handle, the relay allows for easy access and maintenance without compromising security. The handle can be sealed to prevent unauthorized removal, safeguarding against potential operational disruptions.

    With its RS-485 Modbus RTU communication interface, the GE SR469 469-P5-H1-A20-E facilitates seamless integration into existing industrial control systems, enabling remote monitoring and diagnostics. This feature is particularly advantageous for large-scale operations requiring centralized management.

    Certified to meet stringent industry standards, including insulation voltage ratings up to 300VDC and pollution degrees up to 2, the GE SR469 469-P5-H1-A20-E Motor Management Relay is a reliable choice for applications where safety and performance are paramount.
