GE SR469-P5-HI-A20-H – 469 Motor Management Relay with 5A Phase CT and Optional Conformal Coating

Manufacturer:General Electric Company USA

Model:SR469-P5-HI-A20-H

Voltage Supply:AC: 70 to 265 V @ 48-62 Hz

Phase Current:5A Phase

Protocol:Modbus RTU / Half Duplex

Analog Outputs:4-20 mA

Burden:> 500 kΩ

Stall Ratio:Hot and Cold Safe

Optional Features:Ethernet 10BaseT, RJ45 connection

    The GE SR469-P5-HI-A20-H is designed to provide robust protection and monitoring for industrial motors, ensuring optimal performance and longevity. With its advanced RTD inputs, this relay accurately measures motor temperatures and identifies the hottest point within the system, allowing for timely intervention to prevent overheating.

    The relay features a larger LCD display for easy monitoring and configuration, and is equipped with conformal coating to protect against harsh environmental conditions, ensuring reliable operation even in challenging environments.

    Supporting Modbus RTU communication, the GE SR469-P5-HI-A20-H enables seamless integration with existing industrial control systems. Additionally, the optional Ethernet 10BaseT, RJ45 connection allows for remote monitoring and data logging, making it easier to track motor health and system performance.

    Designed with safety and efficiency in mind, the relay offers a range of protective features including torque protection, mechanical jam detection, and undervoltage & overvoltage protection. These features are highly configurable, allowing users to set specific thresholds and response times to suit their operational requirements.

    With its comprehensive protection suite and versatile communication options, the GE SR469-P5-HI-A20-H is an ideal choice for industrial applications where motor reliability and uptime are critical. Its rugged design and advanced features make it a reliable partner in ensuring the smooth operation of your motor systems.
