Interface Type:PCI Express
Sampling Rate:Up to 10 MS/s
Analog Input Channels:16
Analog Input Range:-10 V to +10 V
Digital Input/Output:24 channels
Power Supply Voltage:24 V DC
Operating Temperature:-40°C to +70°C
Dimensions (WxHxD):117.8 mm x 170.5 mm x 46.7 mm
Weight:Approx. 0.65 kg
Introducing the National Instruments PCI-6229, the pinnacle of precision data acquisition modules, specifically tailored for demanding industrial control environments. This module boasts an impressive sampling rate of up to 10 MS/s, ensuring that even the most rapid data streams are captured with utmost accuracy. With its 16 high-resolution analog input channels capable of measuring from -10 V to +10 V, it caters to a wide range of applications requiring precise voltage measurements.
Equipped with 24 versatile digital input/output channels, the PCI-6229 provides a flexible interface for controlling various devices and systems within complex industrial setups. Its robust power supply voltage of 24 V DC ensures reliable operation under a variety of environmental conditions, making it suitable for use in extreme temperature ranges (-40°C to +70°C).
Crafted with a compact yet durable design, the PCI-6229 measures 117.8 mm in width, 170.5 mm in height, and 46.7 mm in depth, fitting seamlessly into standard PCIE slots without compromising performance. Weighing approximately 0.65 kg, it’s lightweight and portable, enhancing its portability and ease of installation.
The PCI-6229 is engineered with cutting-edge technology, ensuring compatibility with the latest software and hardware platforms. It supports real-time data acquisition, analysis, and visualization, providing engineers and technicians with the tools necessary to optimize system performance and troubleshoot issues efficiently.
Designed with user-friendliness in mind, this module simplifies complex data acquisition tasks, reducing setup time and minimizing errors. Whether you’re working on process control, test and measurement, or research applications, the National Instruments PCI-6229 is your go-to solution for high-precision data acquisition, delivering exceptional value and performance.
