Prosoft 5025 BACnet PDPS Module, Industrial Control, Communication Interface

Operating System Compatibility:Windows, Linux, UNIX

Network Protocol Support:BACnet/IP, BACnet MS/TP

Data Transfer Rate:Up to 10 Mbps

Network Connection Type:Ethernet RJ45

Power Supply:DC 12V ± 10%

Dimensions (WxHxD):85mm x 85mm x 35mm

Temperature Range:-10°C to +50°C

Humidity Range:0% to 95% RH, non-condensing

    The Prosoft 5025-BACNET-PDPS gateway is engineered to streamline the connection between two disparate networks, enabling real-time communication and control between Ethernet/IP based industrial automation systems and BACnet managed building automation systems. Its compact and robust design ensures reliable operation in demanding industrial environments.

    Featuring a high-speed Ethernet/IP interface for efficient data transfer, this gateway supports up to 32 BACnet devices, making it suitable for large-scale building automation projects. The integrated BACnet MS/TP interface ensures compatibility with a wide range of BACnet enabled devices, enhancing system flexibility and scalability.

    Equipped with an internal web server, users can remotely monitor and manage the gateway’s status, perform firmware updates, and access comprehensive documentation directly from any web-enabled device. This feature minimizes downtime and simplifies maintenance processes, contributing to overall operational efficiency.

    With its user-friendly interface and straightforward configuration process facilitated by the ProSoft Configuration Builder (PCB) software, the 5025-BACNET-PDPS gateway simplifies the setup and management of complex network architectures. The software supports Windows-based graphical user interface, allowing users to easily configure network settings, view diagnostics, and troubleshoot issues.

    The 5025-BACNET-PDPS gateway complies with industry standards such as IEEE 802.3 for Ethernet and BACnet MS/TP for Building Automation networks, ensuring interoperability and reliability across different systems. Additionally, it adheres to environmental norms like RoHS and WEEE, promoting sustainable manufacturing practices.
