Module Type:IGBT
Rated Current:30 A
Rated Voltage:1200 V
Operating Temperature Range:-40°C to +125°C
Cooling Method:Thermal Pad and Forced Air Cooling
Max Switching Frequency:20 kHz
Insulation Resistance:≥ 10 MΩ @ 500 VDC
Electrical Life:Over 100,000 switching cycles
Introducing the Semikron SKD30/12A1, a cutting-edge power module engineered for optimal performance in industrial control environments. This module is distinguished by its robust design and advanced technology, ensuring seamless integration into complex systems.
Featuring an operating temperature range from -40°C to +125°C, it’s designed to withstand extreme conditions encountered in industrial settings, guaranteeing reliability and longevity.
With a maximum continuous current capacity of 30 A and peak forward current of 60 A, the SKD30/12A1 is capable of delivering high power outputs efficiently, supporting a wide range of industrial applications.
Equipped with a 1200 V RMS voltage rating, this module ensures safety and compatibility across various voltage requirements, making it a versatile choice for diverse industrial systems.
The thermal resistance of 5.5 K/W further enhances its performance, allowing for effective heat dissipation even under heavy load conditions. Coupled with its insulation class, it ensures operational safety and minimizes the risk of electrical accidents.
Manufactured with precision in a TO-247 package type, this power module boasts five leads for easy installation and integration, simplifying system assembly and maintenance processes.
