Frequency Range:0 Hz – 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Resolution:14-bit vertical resolution
Output Amplitude:2 Vpp into 50Ω
Output Impedance:50Ω
Sampling Rate:up to 40 MSa/s
Memory Depth:16 kpts
Interface:USB, LAN, GPIB
The Tektronix 5B42 Arbitrary Function Generator offers exceptional performance for a variety of applications. With its wide frequency range and high-resolution waveform generation capabilities, it is an indispensable tool for testing and calibration processes. Its user-friendly interface allows for easy programming of complex waveforms, making it ideal for both laboratory and production environments. The generator supports multiple waveform types, including sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms, which can be generated with high precision and stability. The device’s memory depth of 16 kpts ensures smooth and accurate waveform playback, while its high sampling rate of up to 40 MSa/s guarantees quick response times. Connectivity options include USB, LAN, and GPIB, allowing seamless integration into various systems and setups. Designed with reliability and ease of use in mind, the Tektronix 5B42 is a robust solution for any demanding application.
