Startup Time:6 ms max.
Control Velocity Output:-10 to 10 V
Data Backup:Backup using the CPU module
External Contact Output:Servo on, driver reset and brake off
Encoder Type:Incremental encoder (phaseA/B)
Maximum Pulse Rate:2 Mpps
Multiplication Mode:4-time multiplication
Control System:Semi-closed loop control (with voltage output for velocity control) based on encoder feedback
External Contact Input:Limit switch, driver alarm, home
The YOKOGAWA F3NC01-0N Positioning Module is a high-performance device designed for demanding industrial environments. With its rapid startup time of just 6ms, this module ensures immediate response times critical for real-time control systems. The -10V to 10V velocity control output provides smooth and accurate motion control, essential for applications requiring fine-tuned adjustments. Data is securely backed up using the integrated CPU module, ensuring continuous operation even in the event of power interruptions. The external contact output functionality allows for seamless integration with various industrial components such as servos, drivers, and brakes, providing comprehensive control over the entire system. The module supports both absolute and incremental encoders, with the latter capable of up to 2 million pulses per second (pps), making it suitable for high-speed applications. The semi-closed loop control system, based on encoder feedback, delivers exceptional precision and reliability. Additionally, the external contact input supports limit switches, driver alarms, and home positions, enhancing safety and operational efficiency. This module is ideal for industries such as manufacturing, robotics, and automation where precision and reliability are paramount.
